15.12 Charger connector This option is a replacement for a charger connector. The charger connector is compatible with the original battery connector.
Figure 150. Charger connector overview
NOTE: Make sure that you set the mechanical voltage selector to the correct battery voltage (24 V)! Also note the polarity of the battery cables.
15.12.1 Replacing the charger connector Instructions for removing the charger connector are provided below. Install the charger connector by repeating the steps in reversed order. 1. Remove the screws holding the charger connector in place. 2. Remove the wires. 3. Remove the charger connector.
