NSR
Service Manual
CONTROL
FUNCTIONALITY DESCRIPTION
Buttons for lifting and lowering initial lift (optional)
Optional for stackers.
Switch for auxiliary device (optional)
Optional for stackers.
Warning light for side stabilizers (optional)
Optional for stackers. The warning light is turned on when the side stabilizers are lowered. The warning light is turned off when the side stabilizers are lifted back up.
15.11 Key switch
Figure 149. Key switch overview
The key switch option replaces the Start button in the control panel and removes the need for a PIN query. The key switch switches the truck's electrical system on and off. When the key switch is in the off position, the truck’s electrical system is turned off. Note however that power may be still connected to certain electronic devices. Type
Key switch
Contact rating
24 Vdc / 6 A
Electrical wiring
Quick connect terminals 2.8 x 0.8 mm
Switching output
2 x NC + 2 x NO, momentary action
