Recharging plug
This option is a replacement for a defective recharging plug.
Figure 96. Recharging plug overview
NOTE: Mak e sure that you set the mechanical voltage selector to the correct battery voltage (24 V)! Also note the polarity of the battery cables.
15.8.1
Replacing the recharging plug
Instructions for removing the recharging plug are provided below. Install the rec harging plug by repeating the steps in reversed order. 1.
Lift the forks of the truck to their upmost position.
