m
Contents
1.
Engine description
1.1
Engine description
The M 25 C is a four-stroke diesel engine, non-reversible, turbocharged and intercooled with direct fuel injection.
In-line engine M 25 C
Cylinder configuration: Bore: Stroke: Stroke/bore ratio: Swept volume: Output/cyl.: BMEP: Revolutions: Mean piston speed: Turbocharging: Direction of rotation: M 25 C Propulsion - 04.2012
6,8,9 in-line 255 mm 400 mm 1.57 20.4 l/Cyl. 317 - 333 kW 25.8 bar 720/750 rpm 9.6/10.0 m/s pulse pressure clockwise, option: counter-clockwise 1
