75 Operation Section Make sure that the work tool that is being used is appropriate for the work that is being performed. Exceeding the machine limits will reduce the service life of the machine. Refer to Operation and Maintenance Manual, "Caterpillar Approved Work Tools" for additional information.
Auxiliary Hydraulic Connections
Illustration 119
g00832864
18. Retract the boom and lower the boom to the travel position before you move the machine or before you raise the stabilizers.
There are many types of work tools from various manufacturers which may be installed on the machine. Caterpillar cannot anticipate every possible work tool and use which may be encountered. When you install a work tool or when you operate a work tool, follow the manufacturer's guidelines and instructions. If you are in doubt, consult your Caterpillar dealer. Your Caterpillar dealer can provide you with further information on the proper installation and use of specific work tools.
Work Tools General Operating Guidelines
Use of non approved work tools on Telehandler machines could result in injury or death. Before installing a work tool on this machine, ensure that it is approved by Caterpillar and that a Caterpillar load chart covering its use is installed in the machine's cab.
NOTICE When certain work tools are fitted, the work tools can contact the front tires or the front fenders. This situation can occur when the boom is retracted and the work tool is rotated fully forward. Always check for interference when first operating a new work tool. NOTICE When certain work tools are installed, the work tools can contact the stabilizers. This interference can occur when the boom is retracted and the work tool is rotated fully forward. Always check for interference when first operating a new work tool. Travel with the work tool lowered as far as possible with adequate ground clearance. Travel with the boom fully retracted so that you have good visibility and so that the machine has good stability. Maintain traction by avoiding excessive downward pressure on the work tool. When the machine is operating on a slope, position the heaviest end of the machine uphill.
Illustration 120
g00975155
On standard machines, a single diverter valve with two quick disconnects is installed. The diverter valve allows the operator to direct hydraulic oil to the hydraulic quick coupler function or to the work tool. Note: The electrical diverter valve may not be installed on certain merchandising arrangements. Consult your Caterpillar Dealer for installation of the connection points for the auxiliary hydraulic service with manual quick couplers. Note: A dual diverter valve is installed as an option. Refer to the topic "Joystick Control" in Operation and Maintenance Manual, "Operator Controls" for more detailed information on operating the boom and the work tools.
Connecting a Work Tool Refer to the procedures that are described in the topic "Quick Coupler" in Operation and Maintenance Manual, "Operation Information" in order to install the work tools.
