Instructions on the replacement of wear parts Tail shaft The tail shaft (Fig. 45) allows for even adjustments friction free transition to the conveyor chain assembly. As soon as any component of the tail shaft is worn the component or complete tail shaft assembly must be replaced. Due to the high abrasion forces the tail shaft is subject to a very high level of wear. The tail shaft assembly consists of the following main components:
shaft roller (2) slide plate key (2) set screw (2) roller bearing (2) piston rod adapter (2) grease fitting (2)
Fig. 45: Tail shaft main components
Roller (2)
Key (2) Set screw (2)
5.58
Tail shaft
Slide plate
Grease fitting (2)
Roller bearing (2) Piston rod adapter (2)
Model 7SFBH-56 Feeder Breaker
