300 Foot Requirements Component
Wire Type of Wire Size (AWG) Three-Wire Sensors 16 Shielded twisted triad cable is recommended. For (when applicable. Not used on all systems)
Two-Wire Components (Magnetic Speed Sensors and some data links)
Engine Solenoids (Air Shutoff) Power
(1)
Connections(1)
Deutsch DT type of connectors are recommended. If Spring Spade or Ring Terminals are used, the connection between the 16 or 18 Shielded twisted pair cable is recommended. For conduits terminals and the inside facilities, use the 123-2376 Electrical Cable or the wire should be 3E-4594 Electrical Cable. For the engine harness, use the crimped and 6V-2744 Wire. The cable must be resistant to fuel and oil. soldered. The cable must have a temperature range of minus 40º C (40º F) to plus 125º C (257º F). conduits inside facilities, use Belden 8618. For the engine harness, use the 4G-2556 Shielded Cable. The cable must be resistant to fuel and oil. The cable must have a temperature range from minus 40 C (40 F) to plus 125 C (257 F).
8
Stranded wire normally used on engine harnesses. The cable must be resistant to fuel and oil. The cable must have a temperature range of minus 40º C (40º F) to plus 125º C (257º F).
The leads of the cable should have Spring Spade Terminals or Ring Terminals. The Connection between the wire and the terminal should be crimped and soldered.
The number of connections must be kept to a minimum.
Shielded Wiring The shielded twisted pair cable was selected for the J1939 data links and the magnetic speed sensor. These cables were chosen for maximum protection against inductive noise. The cables are also protected from electromagnetic interference and radio frequency interference. The shield greatly reduces the amplitude of any unwanted voltages on the signal wire. If the shields are connected to sheet metal, the connections are susceptible to loose bolts, corrosion, etc. The faulty connections increase the resistance of the shield. Faulty connections also reduce the effectiveness of the shield. All the shields of the shielded cable must be connected to the common battery negative terminal of the generator set only. The shields should not be connected to the sheet metal. Sheet Metal connections corrode over time, increasing the resistance on the shield. When the cable terminates at junction boxes, the shields must be connected to each other in order to maintain a continuous path. Wire exposed beyond the shield should be as short as possible, and not exceeding two inches. To avoid electromagnetic interference, do not run shielded signal wires near other wires carrying large currents. In installations with unavoidable risk of electromagnetic
