Appendix B Blocks for Setpoint Configuration This appendix contains information on the various software blocks in the EMCP 3 control. Blocks are functional groups of setpoints. Blocks can occur in multiple instances, and in order to program a setpoint, the block number as well as the instance number must be referenced. Table 12: Blocks for Setpoint Configuration
Block #
Block Name
EMCP 3.2 EMCP 3.3 Number Number of of Instances Instances
1
Engine Oil Pressure Monitor
1
1
4
Engine Coolant Temperature Monitor
1
1
6
Engine Speed Monitor
1
1
7
Battery Voltage Monitor
1
1
8
Engine Operating Hours Monitor
1
1
9
Crank Attempt/Successful Start Counter
1
1
10
Engine Protection Events Configuration
1
1
11
Generator Protection Events Configuration
1
1
12
Other System Events Configuration
1
1
17
Diagnostics Configuration
1
1
18
Automatic Start/Stop
1
1
19
Generator AC Monitor
1
1
21
Generator Over/Under Voltage
1
1
22
Generator Over/Under Frequency
1
1
23
Generator Over Current
1
1
24
Generator Reverse Power
0
1
34
Utility Breaker Control
1
1
35
Generator Breaker Control
1
1
53
Digital Inputs
8
8
56
Relay Outputs
8
8
72
Event System
1
1
75
Electronic Control Module Reduced Power Mode
1
1
88
Digital Outputs
1
2
94
Data Link - SCADA
1
1
96
Enhanced Engine Monitor
0
1
97
Event Output Functions
30
30
98
Generator AC Power Monitor
1
1
100
Service Maintenance Interval
1
1
102
Governor Desired Engine Speed Request
1
1
104
Digital Selectors
10
10
