OPERATING INSTRUCTIONS After excavator removal, set transmission to the start condition carrying out the above described operations in reverse.
3
WARNING During removal do not allow anybody to get too close to the machine. Use a second operator as a signalman for operation coordination. F5859B
WARNING Reset parking negative brake and bring gearbox lever back to normal conditions when excavator removal is no longer necessary.
26601 6-29950 GB
SPEED SENSOR In the rear axle is located the transmission housing. On the right side is speed sensor (1). Each time its replacement is required: • Disconnect the electrical cable from sensor (1). • Untighten nut (2) and unscrew sensor (1) progressively. For speed sensor assembly: • Tighten sensor (1) to the stroke, back-up by 2 turns. Lock in position with nut (2). • Connect sensor (1) to the electrical cable.
1
2
F8381
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
