OPERATING INSTRUCTIONS
Load handling (continued)
Template Name: OM_1_col Template Date: 1994_04_29
- Check that the safety valves function correctly. The pressure setting must be checked every 6 months, in conformance with prevailing regulations and/or the maker’s instructions. Consult your CASE Dealer. - Make sure the load handling chart is in the dust jacket specially provided and that it corresponds to the machine version and the attachment mounted. See “Load handling limits”. - Place the overload indicator switch on the left-hand control arm in “ON” position. This is mandatory. See “Left-hand control arm” (item 6) in the “Controls/Instruments/Accessories” Section. - Select the “L” (light) work mode. See “Systems display and control panel” (item 2), in the “Controls/Instruments/Accessories” Section. - Do not exceed the limits shown on the load handling chart. To obtain a load handling chart, consult your CASE Dealer, giving full particulars of the machine model number, the weight of the counterweight, plus the length and type of boom and dipper.
TRIM THIS EDGE
- Do not allow anyone within the machine’s operating radius. - Operate the controls smoothly to ensure precise movement of the attachment and the machine. - Stabilize the load a few centimeters above the ground to make sure it is perfectly balanced before trying to move it.
Alt= to hide template information Alt+ to display template information
- All movements must be sure and smooth. Moving quickly does not mean moving roughly. - When traveling with a load, make sure you do the following : - Place the upperstructure in line with the undercarriage. - Bring the load as close as possible to the undercarriage and the ground. - Be sure all travel is undertaken in slow speed only. NOTE: Load handling on CASE machines is in conformity with standard EN 474-1 and standard 474-5 relative to directive 98/37/EC.
92
