CONTROLS/INSTRUMENTS/ACCESSORIES
IMPORTANT: The quick coupler eye can be used for handling loads up to 5 tonnes. See “Load handling” in the “Operating Instructions” Section. IMPORTANT: This attachment point will only carry the load indicated in the maximum lift capacities table. See “Maximum lift capacities tables” in the “Operating Instructions” Section. CD00E159
TRIM THIS EDGE
!
WARNING: Never use the front or rear fixing points on the quick coupler (optional) to carry out load handling operations.
CD00H002
Alt= to hide template information Alt+ to display template information
LOAD HANDLING EYES
!
WARNING: Never weld hooks or lugs on the bottom plate of the bucket for handling operations. The only attachment point which may be used is the connecting rod eye.
!
WARNING: Never use the connecting rod eye if the bucket has been removed.
79
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
When lifting loads, the slings and chains must be attached to the load handling eye on the bucket control rod or the quick coupler (optional).
