CONTROLS/INSTRUMENTS/ACCESSORIES
FUEL TANK Template Name: OM_1_col Template Date: 1994_04_29
NOTE: In cold weather, use fuel corresponding to the ambient temperature. See “Fluids and lubricants” in the “Lubrication/Filters/Fluids” Section. IMPORTANT: In cold weather, fill the fuel tank after each working day to prevent the formation of condensation. When installing the fuel cap, make sure that it is correctly placed in the notches and then lock it by turning it up against the stop.
CD00E154
The fuel tank capacity is 250 litres.
TRIM THIS EDGE
NOTE: Clean around the fuel cap before refuelling and do not remove the filter located in the filler orifice. See “Fuel tank filter” in the “Maintenance/Adjustments” Section.
!
WARNING: Never refill the fuel tank when the engine is running. Never smoke during refuelling.
NOTE: Use the starter switch key to lock the fuel cap.
CAB GUARD (F.O.P.S.)
Alt= to hide template information Alt+ to display template information
The use of guard is imperative when operating in zones where the possibility of falling stones or debris exists. In the event the machine is not originally equipped with this guard, it is possible to have it installed, see your CASE Dealer.
CT04D008
74
