MAINTENANCE/ADJUSTMENTS
Torque (Nm)
Travel reduction gear (*)
M16
24
267-312
Drive sprocket (*)
M16
24
267-312
Idler wheel (*)
M16
24
267-312
Upper roller (*)
M16
24
267-312
Lower roller (*)
M16
24
267-312
Track bad
M16
24
392-430
Counterweight
M27
41
844-980
Turntable bearing (undercarriage)
M16
24
280-322
Turntable bearing (upperstructure)
M16
24
280-322
Swing reduction gear (*)
M16
24
280-322
Engine (*)
M16
24
265-313
Engine mounts (*)
M10
17
64-73
Radiator
M12
19
64-73
Hydraulic pump (*)
M10
17
63-72
Hydraulic reservoir (*)
M16
24
206-247
Fuel tank (*)
M16
24
206-247
Control valve (*)
M16
24
267-312
Hydraulic swivel (*)
M12
19
109-127
Cab
M16
24
78-80
Batteries
M10
17
20-29
NOTE: Use Loctite 262, or the equivalent, on screws marked (*).
211
TRIM THIS EDGE RIGHT PAGE
Alt= to hide template information Alt+ to display template information
Wrench (mm)
Template Name: OM_1_col Template Date: 1994_04_29
Screw (Ø)
Component
TRIM THIS EDGE
Torque specifications per component
