OPERATING INSTRUCTIONS
- Make sure the load handling chart is in the dust jacket specially provided and that it corresponds to the machine version and the attachment mounted. See “Load handling limits”. - Place the overload indicator switch on the left-hand control arm in “ON” position. This is mandatory. See “Left-hand control arm” (item 6) in the “Controls/Instruments/Accessories” Section. - Select the “L” (light) work mode. See “Systems display and control panel” (item 2), in the “Controls/Instruments/Accessories” Section. - Do not exceed the limits shown on the load handling chart. To obtain a load handling chart, consult your CASE Dealer, giving full particulars of the machine model number, the weight of the counterweight, plus the length and type of boom and dipper.
- Operate the controls smoothly to ensure precise movement of the attachment and the machine. - Stabilize the load a few centimeters above the ground to make sure it is perfectly balanced before trying to move it. - All movements must be sure and smooth. Moving quickly does not mean moving roughly.
TRIM THIS EDGE
- Do not allow anyone within the machine’s operating radius.
Alt= to hide template information Alt+ to display template information
- Check that the safety valves function correctly. The pressure setting must be checked every 6 months, in conformance with prevailing regulations and/or the maker’s instructions. Consult your CASE Dealer.
- When traveling with a load, make sure you do the following : - Place the upperstructure in line with the undercarriage.
- Be sure all travel is undertaken in slow speed only. NOTE: Load handling on CASE machines is in conformity with standard EN 474-1 and standard 474-5 relative to directive 98/37/EC.
103
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
- Bring the load as close as possible to the undercarriage and the ground.
