VI. Service and maintenance
G. Auto lubrication system (ALS) Auto lubrication system is available as an option upon request. Contact your authorized dealer.
a) Vibrating type ALS for CB80, CB140, CB210, CB380
CB80
1. Grease refill port 2. Manual greasing port 3. Grease output regulator
CB140 , CB210, CB380
• ALS is operated by vibration of the breaker during operation. Grease output can vary on the breaker working condition. • Grease output can be adjusted with regulator. • In case greasing by vibrating ALS is not sufficient despite of setting regulator to maximum output, apply manual greasing until the breaker has been fully lubricated.
42
