INSTRUMENTS/CONTROLS
PARKING BRAKE
GROUP 5 CAB The cab provides operator comfort in any ambient condition.
1
The parking brake is hand operated. When the lever is pulled up, the ratchet teeth allow a partial or full brake application (the lever system permits other actuation positions).
1. DOOR
To release the brake, pull the lever slowly upward, press the lock button (A) and push the lever down.
Turning the handle (1), the door opens. To keep the door opened while operating the machine or servicing cab, open the door until it reaches the automatic lock.
2
Pull lever (2) to release the automatic lock. This lever is located inside the cab, to the operator’s left.
52
