INSTRUMENTS/CONTROLS
D. TRANSMISSION OIL PRESSURE GAUGE
8. IGNITION SWITCH
The marker of the transmission oil pressure gauge must stay within the green area which indicates normal operating pressure. If the marker enters the red area, it is a signal that the oil pressure is too low.
This switch is a rotary type and is activated with a key. It has four positions: OFF
Do not operate the machine with low transmission oil pressure. Stop and check the cause of the problem.
ACC
E. TRANSMISSION OIL TEMPERATURE GAUGE
RUN
START
The marker must register in the green area. Do not operate the machine when the gauge is in the red area. Stop the machine and determine the cause of high temperature.
ACC - Acessories
6. MASTER SWITCH
In this position some circuits such as the wipers and lights, are energized for use. OFF
The machine electrical functions can only be actuated if the rotary master switch is activated.
In this position all key activated electrical circuits are off. The key can be removed.
The master switch is activated by the starting switch in the “ON” position.
RUN In this position all key activated electrical circuits are “ON”.
7. AUXILIARY ELECTRICAL CURRENT RECEPTACLE
START In this position, the starting circuits are energized. The switch is spring controlled for start and will return to the “RUN” position when the key is released. CAUTION: Never leave the key in the “ON” position when the engine is not running.
The machine is equipped with a 24V auxiliary electrical power supply.
46
