INSTRUMENTS/CONTROLS
5. GAUGE PANEL
A. ENGINE OIL PRESSURE GAUGE The engine oil gauge indicates the pressure at which the engine oil is circulating through the engine. 1. CAB HEAT CONTROL
The red area means insufficient pressure.
To increase the temperature in the cab, turn the cab temperature control knob clockwise. To decrease the temperature in the cab, turn the cab temperature control knob counterclockwise.
The green area means normal operating pressure, and the yellow area, excessive engine oil pressure. B. ENGINE COOLANT TEMPERATURE GAUGE
2. BLOWER FAN SPEED SWITCH To increase the cab blower fan speed, turn the cab blower fan control counterclockwise until the desired fan speed is obtained.
•
The marker in the GREEN area indicates the normal operating temperature range 80 to 95°C (176 - 203°F)
The blower fan speed switch has four positions: 1. OFF 2. Low 3. Medium 4. High
•
The WHITE area indicates low temperature.
•
The RED area indicates high temperature.
If during the work cycle, the coolant temperature stays either in the WHITE or RED area, stop the engine to check the cause of the problem. C. FUEL LEVEL INDICATOR GAUGE The green area indicates the normal operating level. Refill the tank using filtered fuel as recommended. Refill the tank at the end of each work day, to avoid water condensation. Never let the fuel tank run-dry, this will cause air to enter the fuel system. Never refill the fuel tank with the engine running.
45
