INSTRUMENTS/CONTROLS
8. LIMP-HOME SWITCH
15. WORK LIGHTS SWITCH
This switch is used to move the machine in the event of a transmission electronic control unit problem. The rocker switch has three positions: Forward, Neutral and Reverse.
This switch activates the work lights above the moldboard and below the cab. The work lights switch is a three-position switch. The first position turns the lights OFF.
The switch must be in the Neutral position with the park brake applied to start the machine, when the limp-home mode is activated.
To turn on the lights above the moldboard, push the symbol side of the rocker switch to the second position.
The transmission shifter and the inching pedal are bypassed when in the limp-home mode. See the Maintenance Section for more details on how to activate the limp-home mode.
To turn on the lights under the cab, push the symbol side of the rocker switch to the third position. The lights above the moldboard will stay on with the switch in the third position.
9. FRONT WINDSHIELD WIPER SWITCH
16. REAR FLOODLIGHT SWITCH
This switch is used to activate the front windshield wiper.
This switch activates the rear floodlights. To turn on the rear floodlights, push the symbol side of the rocker switch.
The rocker switch has three positions: OFF, Low and High.
17. FRONT FLOODLIGHT SWITCH
10. FRONT WINDSHIELD WASHER SWITCH
This switch activates the front floodlights.
This switch is used to activate the front windshield washer.
To turn on the front floodlights, push the symbol side of the rocker switch.
11. REAR WINDOW WIPER SWITCH This switch is used to activate the rear window wiper. The rocker switch has three positions: OFF, Low and High. 12. REAR WINDOW WASHER SWITCH This switch is used to activate the rear window washer. 13. AIR CONDITIONER SWITCH This switch activates the cab air conditioner. To turn the air conditioner on, push on the symbol side of the rocker switch. 14. CAB AIR RECIRCULATION SWITCH This switch closes the cab recirculation door to prevent outside air from coming into the cab. To close the reciruclation door to recirculate the cab air, push on the symbol side of the rocker switch. 44
