INSTRUMENTS/CONTROLS
2. THROTTLE CONTROL LEVER
GROUP 3 Dashboard, transmission control lever, throttle control lever, fuse box and master switch.
2
3
5
6 1
7
4
The engine will remain at low idle with the throttle control lever all the way forward and engine speed will increase as the lever is pulled back.
8
3. TRANSMISSION CONTROL LEVER 1. 2. 3. 4. 5. 6. 7. 8.
FUSE BOX THROTTLE CONTROL LEVER TRANSMISSION CONTROL LEVER TOGGLE/ROCKER SWITCH PANEL GAUGE PANEL IGNITION SWITCH MASTER SWITCH POWER TAKE OFF
1. FUSE BOX
SHIFT PATTERN: R • REVERSE F • FORWARD N • NEUTRAL DS • DOWN SHIFT UP • UP SHIFT
In the fuse box are installed all the grader fuses. For the identification of the fuses, refer to the electrical diagram.
41
