ELECTRICAL SYSTEM
FUSE BOX The fuse box is located inside the right console. To access the fuses for replacement or service of fuse box, open the front cover of the console.
Fuse and Relay List Fuse Box 1 F1 - Turn signal and hazard warning light fuse F2 - Dual power solenoid and power outlet fuse F3 - Dome lights and strobe lights fuse F4 - Head lights low beam fuse F5 - Horn fuse F6 - E.D.M (electronic data monitor) and buzzer fuse F7 - Transmission fuse F8 - Transmission fuse F9 - Transmission fuse F10 - Cab fan fuse F11 - Front wiper and washer fuse F12 - Solenoid valves auxiliary hydraulic fuse F13 - Rear work iight fuse F14 - Headlights high beam fuse F15 - Cold starting fuse F16 - Rear wiper and washer fuse
Fuse Box 2 F1 - Air conditioning fuse F2 - Air conditioning fuse (not used) F3 - Air conditioning fuse (not used) F4 - Recirculation air conditioning fuse F5 - Front wheel drive fuse F6 - Differential lock fuse F7 - Back-up alarm fuse F8 - Fuel shutoff solenoid fuse (hold solenoid) F9 - Brake light fuse F10 - Lower front wiper lower and washer fuse F11 - Cab light fuse F12 - Work light fuse (After blade) F13 - Work light fuse (before blade) F14 - Radio fuse F15 - Lift fuel Pump fuse (not used) F16 - Front attachment light fuse (opt.) R1 - Safety fuel lift electric pump relay (not used) R2 - Safety fuel lift electric pump relay (not used) R3 - Auxiliary starter relay R4 - Headlights low beam relay R5 - Headlights high beam relay R6 - Rear work lights relay R7 - Horn relay R8 - Back-up alarm relay R9 - Cold Starting relay R10 - Differential lock relay R11 - Dual power solenoid relay R12 - Air conditioning blower fan relay R13 - Air conditioner heat fan relay R14 - Front attachment work light relay
