EXCAVATOR IDENTIFICATION
3
25
2
25
1
24 15
16
4
5
17
14 6
23 13 10
7 18
8
22 11
12
20
19
21 NA1400B NA1401B
ITEM
DESCRIPTION
ITEM
DESCRIPTION
1
Operator’s Handbook
16
Cab (ROPS / TOPS) [2]
2
Arm Cylinder
17
Tailgate
3
Auxiliary Quick Couplers
18
Counterweight
4
Boom
19
Tracks [3]
5
Arm
20
Tie Downs (Both Sides)
6
Bucket Cylinder
21
Track Frames
7
Bucket Link
22
Blade
8
X-CHANGE™
23
Right Side Cover
9
Bucket [1]
24
Lift Point
10
Boom Cylinder
25
Mirrors (If Equipped)
11
Tie Downs / Lift Points
12
Blade Cylinder
13
Upperstructure
14
Control Levers (Joysticks)
15
Operator’s Seat with Seat Belt
[1] BUCKET - Several different buckets and other attachments are available for the Bobcat excavator. [2] ROPS / TOPS - (Roll-Over Protective Structure / Tip-Over Protective Structure) as standard equipment. The ROPS / TOPS meets ISO 12117-2:2008, ISO 12117: 2000 and EN13531:2001. [3] TRACKS - Optional tracks are available.
9 11 of 190
E32 Operation & Maintenance Manual
