DIAGNOSTICS SERVICE CODES (CONT'D) Number Codes List (Cont’d)
25-02
CODE
25-03
Rear auxiliary relief solenoid error ON Rear auxiliary relief solenoid error OFF
26-02 26-03
Front base solenoid error ON Front base solenoid error OFF
27-02 27-03
Front rod solenoid error ON Front rod solenoid error OFF
28-02 28-03
Diverter solenoid error ON Diverter solenoid error OFF
32-63 32-64 32-65 32-66 32-67 32-68 32-69 32-70 32-71
29-02
High flow solenoid error ON
33-23
Main Controller (Bobcat Controller) not programmed
29-03
High flow solenoid error OFF 34-04
Deluxe panel no communication to Bobcat controller
35-02 35-03
Two-speed fan error ON Two-speed fan error OFF
36-48
ACD multiple controllers present
37-02 37-03
Two-speed secondary error ON Two-speed secondary error OFF
30-28
Controller Memory failure
31-28
Interrupted power failure
32-04 32-23 32-31 32-32 32-33 32-34 32-35 32-36 32-37 32-38 32-39 32-40 32-41 32-49 32-50 32-51 32-52 32-53 32-54 32-55 32-56 32-57 32-58 32-59 32-60
ACS not communicating with Bobcat Controller ACS Not calibrated Tilt actuator fault Tilt actuator wiring fault Tilt handle wiring fault Tilt actuator not in neutral Tilt handle/pedal not in neutral Lift actuator fault Lift actuator wiring fault Lift handle wiring fault Lift actuator not in neutral Lift handle/pedal not in neutral No communication Lift actuator short to ground Tilt actuator short to ground Lift actuator short to battery Tilt actuator short to battery Lift handle/pedal short to ground Tilt handle/pedal short to ground Lift handle/pedal short to battery Tilt handle/pedal short to battery Lift actuator reduced performance Tilt actuator reduced performance Lift actuator wrong direction Tilt actuator wrong direction
113 of 136
32-61 32-62
Handle lock short to ground Handle lock short to battery Pedal lock short to ground Pedal lock short to battery Sensor supply voltage out of range Battery voltage out of range Switch flipped while operating Lift handle information error Control pattern switch flipped while operating Right drive handle short to ground Right drive handle short to battery
SA-5
773, 773H Bobcat Loader Operation & Maintenance Manual
