STARTING THE ENGINE (Cont’d)
A
Do not use ether with glow plug (preheat) systems. Explosion can result which can cause injury or death. W–2071–1285
Cold Temperature Starting Condition (Optional) See Normal Starting Condition, Page 16. T urn the key switch to the ON position (readout codes will show first) and the glow plug symbol will be ON [A].
The alpha numeric display will indicate the characters GLOXX where XX will show remaining time the glow plugs will be energized. The following chart shows the time glow plugs will be energized dependent on engine coolant temperature. COOLANT TEMPERATURE 0oF. (–18oC.) & Below 05–505F. (–185–105C.) 505–705F. (105–215C.) 705F (215C) & Above
35 of 100
GLOW PLUG ‘‘ON’’ TIME 25 Seconds 15 Seconds 5 Seconds NO TIME
B–12914
–17–
Dealer Copy -- Not for Resale
NOTE: If display is showing readout codes the timing of the glow plug activation may be obscured on the display. However, the glow plugs will actually be energized.
753L Bobcat Loader Operation & Maintenance Manual
