AIR CLEANER SERVICE
A
Replacing Filter Element
1
Condition Indicator:
2
Replace the large (outer) filter element only when the red ring shows in the window of the condition indicator (Item 1) [A]. NOTE: Before replacing the filter element, push the button on the condition indicator (Item 2) [A]. Start the engine. If the red ring does not show, do not replace the filter element. Replace the inner filter every third time the outer filter is replaced or when the red ring still shows in the indicator window after the outer filter has been replaced.
P–10308
1
P–10313
C
Remove the dust cover [C]. Remove the wing nut (Item 1) [C] from the large air filter element.
1
P–10314
68 of 116
48
751 Bobcat Loader Operation & Maintenance Manual
Dealer Copy -- Not for Resale
B
Remove the dust cover wing nut (Item 1) [B].
