INSTRUMENT PANEL
A
The following items are located on the instrument panel [A] and [B]:
8
7
6
9
1. TRACTION LOCK OVERRIDE BUTTON – (Functions Only When The Seat Bar Raised) Allows you to use the steering levers to move the loader forward or backward when using the backhoe attachment or for loader service. (See Page 5.)
10 5 TRACTION LOCK OVERRIDE
2. SEAT SENSOR OVERRIDE BUTTON (If Equipped) (Functions Only When The Seat Bar Is Down) Allows operator, when seated with the seat bar lowered, to use lift, tilt, and traction functions if the seat sensor cannot be activated. (See Page 5.)
3
4 2
SEAT SENSOR OVERRIDE
1
P–13024
B
3. KEY SWITCH – For starting, stopping the engine.
5. HAZARD SWITCH (FA) – Controls the available hazard indicators.
11
12
6. LIGHT SWITCH (Opt. or FA) – Controls the work and travel lights.
13
7. PREHEAT BUTTON – For preheating the glow plugs to aid cold temperature starting.
P–09789
8. BUCKET LEVEL SWITCH (Opt. or FA) – Controls the ON/OFF function of the available bucket position valve. 9. ENGINE WARNING LIGHT – Light is ON when engine oil pressure is low or coolant temperature is high. Stop the engine if the light comes ON. 10. TRANSMISSION WARNING LIGHT – Low transmission charge pressure, hydraulic filter needs replacement or high fluid temperature. Stop the engine if the light comes ON.
Dealer Copy -- Not for Resale
4. BEACON SWITCH (Opt. or FA) – Controls the available flashing beacon light.
11. HOURMETER – Records the total operating hours of the loader. 12. VOLTMETER – Shows the condition of the battery and the rate of charge. 13. ENGINE TEMPERATURE GAUGE – Shows the engine coolant temperature. Opt. – Factory Installed Option FA – Field Installed Accessory – See your Bobcat loader dealer about available Field Accessories.
23 of 96
–3–
453 Bobcat Loader Operation & Maintenance Manual
