OPERATING PROCEDURE (CONT’D)
Figure OI-118
Boom Swing Figure OI-116
B-19996
Slew the upperstructure, swing the boom to th e right [Figure OI-116], center [Figure OI-117] and left [Figure OI-118] to dig a square hole the width of the machine without repositioning the excavator.
B-19994
Figure OI-117
Dealer Copy -- Not for Resale
Figure OI-119
B-19995 B-19937
The boom swing allows the operator to offset the boom and dig close to bu ildings and other structures [Figure OI-119].
OI-53 75 of 174
337, 341 Operation & Maintenance Manual
