Replacing the USB/LED/Power/Card Reader Board IMPORTANT:Before installing the USB board, take care of the following items: • •
Check that LED isn`t broken SLIDER work smoothly
1. Connect the cable to the board.
2. Turn the board over and place it in the lower case.
3. Replace the three or four screws (depending on SKU) to secure the module.
HDD SKU
4. Connect the FFC cable to the module and close the cable latch.
72
SSD SKU
5. Connect the FFC cable to the mainboard and close the cable latch.
Chapter 3
