DOS Flash Utility Perform the following steps to use the DOS Flash Utility: IMPORTANT:Use USB KEY, USB HDD, DVD-RW, and HDDs that can boot to DOS mode. 1.
Press F2 during boot to enter the Setup Menu.
2.
Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
Information
Main
Advanced
InsydeH20 Setup Utility Security Power Boot Exit
Rev. 3.0 Item Specific Help
Boot priority order: 1. 2. 3. 4. 5. 6.
F1 Help ESC Exit
32
Use < > or < > to select a device, then press <F5> to move it down the list, or <F6> to move it up the list. Press <Esc> to escape the menu
IDE0 : ST960821A IDE1 : MATSHITADVD USB FDD : Network Boot : Realtek Boot Agent USB HDD : USB CDROM :
Select Item Select Menu
F5/F6 Enter
C h a n g e Va l u e s Select SubMenu
F9 F10
Setup Default Save and Exit
3.
Execute the FLASH.BAT batch file to update BIOS.
4.
In flash BIOS, the message Please do not remove AC Power Source displays. If the AC power is not connected, the following warning displays:
Chapter 2
