Post Codes These tables describe the POST codes and descriptions during the POST. Post Code Range Phase
POST Code Range
SEC
0x01 - 0x0F
PEI
0x70 - 0x9F
DXE
0x40 - 0x6F
BDS
0x10 - 0x3F
SMM
0xA0 - 0xBF
S3
0xC0 - 0xCF
ASL
0x51 - 0x55 0xE1 - 0xE4
PostBDS
0xF9 - 0xFE
InsydeH2ODDT™ Reserve
0xD0 - 0xD7
OEM Reserve
0xE8 - 0xEB
Reserved
0xD8 - 0xE0 0xE5 - 0xE7 0xEC - 0xF8
SEC Phase POST Code Table Functionality Name (Include\ PostCode.h)
Phase
Post Code
Description
SEC_SYSTEM_POWER_ON
SEC
1
CPU power on and switch to Protected mode
SEC_BEFORE_MICROCODE_PATCH
SEC
2
Patching CPU microcode
SEC_AFTER_MICROCODE_PATCH
SEC
3
Setup Cache as RAM
SEC_ACCESS_CSR
SEC
4
PCIE MMIO Base Address initial
SEC_GENERIC_MSRINIT
SEC
5
CPU Generic MSR initialization
SEC_CPU_SPEEDCFG
SEC
6
Setup CPU speed
SEC_SETUP_CAR_OK
SEC
7
Cache as RAM test
SEC_FORCE_MAX_RATIO
SEC
8
Tune CPU frequency ratio to maximum level
SEC_GO_TO_SECSTARTUP
SEC
9
Setup BIOS ROM cache
SEC_GO_TO_PEICORE
SEC
0A
Enter Boot Firmware Volume
NOTE: The color bar items indicate 3rd party related functions that are platform dependent.
