Hardware Specifications and Configurations Processor Item CPU type
Specification ®
®
Intel Pentium M Processor at 1.5 ~2.13 GHz or higher Intel® Celeron® M Processor at 1.3~1.5 GHz or higher
CPU package
uFPGA 478
CPU core voltage
Depend on DVI
CPU I/O voltage
1.2V
System Board Major Chips Item System core logic
Controller ®
Intel 915PM / ICH6-M Intel® 915GM / ICH6-M
Super I/O controller
KBC (97551), LPC interface
Audio controller
Conexant Codec
Video controller
ATI M26P(Manufacturing option) UMA
Hard disk drive controller
ICH6-M
Keyboard controller
KBC 97551
IrDA controller
SIO 87383
DVI controller
CH7307
PCMCIA/ card reader / 1394 controller
TI PCI7411
DDR-soDIMM controller
915PM/915GM
BIOS Item
Specification
BIOS vendor
Phoenix
BIOS Version
Phoenix First BIOS
BIOS ROM type
Flash ROM
BIOS ROM size
512KB
BIOS package
32 lead of TSSOP
BIOS password control
Set by setup manual
Item
Specification
Cache controller
Built-in CPU
Cache size
2 MB
1st level cache control
Always enabled
2nd level cache control
Always enabled
Cache scheme control
Always enabled
Chapter 1
21
