Bottom View

Item

Chapter 5

Description

Item

Description

1

Keyboard controller

2

Keyboard connector

3

Lid switch connector

4

System fan connector

5

PCMCIA card reader

6

Function key board connector

7

Touch pad board connector

8

Speaker connector

9

Bluetooth module connector

10

LCD cable connector
