Chapter 1
System Tour Features Your Aspire 5910 is part of the Acer Gemstone line of notebook computers. It provides superior computing performance and excellent audio-visual experience in an all new sleek and elegant exterior. NOTE: The features listed in this section is for your reference only. The exact configuration of your Aspire computer depends on the model purchased.
Computing platform T
Mobile technology: Intel® Centrino® Duo mobile technology
T
Processor: Intel Core™ 2 Duo processor. Your Aspire notebook supports the following processor sequence: T7600, T7400, T7200, T5600, and T5500.
T
Processor technologies
T
t
Intel Virtualization Technology (Intel VT)
t
Enhanced Intel SpeedStep® Technology
t
Intel 64-bit architecture
t
Execute Disable Bit functionality
Core logic: Mobile Intel 945PM Express Chipset
Memory T
Two DIMM slots supporting DDR2 533/667 MHz memory modules
T
Maximum 4 GB system memory using two soDIMM modules
T
Supports dual-channel memory mode
T
1 MB flash BIOS and shadow RAM support
Storage subsystem T
SATA hard disk drives in 80–,120–, and 160 GB capacities (higher HDD capacity supported)
T
DVD-Super Multi double-layer drive or DVD/CD-RW combo drive
T
5-in-1 card reader slot supports Secure Digital (SD), MultiMediaCard (MMC), Memory Stick® (MS), Memory Stick Pro™ (MS Pro), and xD-Picture Card™ (xD) formats
Display and graphics T
15.4" WXGA high-brightness (220-nits) Acer CrystalBrite™ TFT LCD (1400 x 900 pixel resolution, 16.7 million colors)
T
Graphics controller: ATI Mobility™ Radeon™ X2300 HD
T
Acer GridVista™ for simultaneous multi-window viewing (8 ms response time)
T
Acer Arcade™ featuring Acer CinemaVision™ and Acer ClearVision™ technologies
T
Supports the following video capabilities: t
Dual independent display
t
MPEG-2/DVD hardware-assisted function (full decode)
t
WMV9 (VC-1) and H.264 (AVC, full decode)
t t
Chapter 1
S-video/TV-out (NTSC/PAL) True Digital Visual Interface (DVI-D) with support for High-bandwidth Digital Content Protection (HDCP)
