Crown wheel and pinion and differential Refitting the differential – Sling the differential assembly using one of the crown screws . – Place the assembly in its housing.
Fig. 98
455hsm59
– Refit the retainer with the screws (A). – Refit the nut (B) using tool n° 00 1136 021 0 then the retainer (C). If shimming has not been performed, pre-tightening is enough. Note: If shimming has been performed, tighten the screws fastening the bracket (A) at 16 ± 1 daN·m, and the nut (B).
A
Ensure you check the torque, which must be included between 0,42 ± 0,1 daN·m. If not, increase or reduce tightening of the nut (B) to be within tolerance. Note: as an indication, the nut (B) must be tightened at about 4 daN·m. – Clamp using the retainer (C) at 2 ± 0,5 daN·m.
B 455hsm60
Axion 850-810 – 10.2010 – GB
C Fig. 99
D1.47
