Crown wheel and pinion and differential Installing the differential – Refit the O-rings (A) into the casing, piston side. – Assemble the piston with the press, then refit it in its housing. – Clamp with the retainer ring.
A
B
Fig. 93
455hsm45
Note: to facilitate refitting with the centering pin (B), make a mark (C) on the piston and casing. – Assemble the differential assembly. – Use "CLAAS Agrigrease EP2" to grease the pinion rods and washers.
C
Fig. 94
455hsm46
– Assemble the casings by matching the marks (R). – Smear the screws with Loctite (270) and tighten at 12 ± 1 daN·m.
R
455hsm95
