Universal joint shaft Exploded view 20.29 SI
132 130 129 131 130 129 5 16 21
133
10
128 127
130
126
129
125 124 123 130
140 71
134 135
70 136
144
137 138 139 141 142 143
452msm0e
Fig. 58
Description 5 Universal shaft.
127 Circlip.
136 Seal.
10 Circlip.
128 Circlips.
137 Bush.
16 Washers.
129 Spider.
138 Bearing.
21 Washer.
130 Circlips.
139 Circlips.
70 Locknut.
131 Body.
140 Screw.
71 Screw.
132 Countershaft.
141 Universal joint protector .
123 Seal.
133 Rear axle shaft.
142 Screw.
124 O-ring.
134 Intermediate end fitting.
143 Bearing.
125 Bush.
135 Circlip.
144 Seal.
126 Bearing.
D2.40
Arion 640-510 – 12.2008 – GB
