Suspension cylinder and lower arm Description 77 Screw.
93 Lower arm.
109 Screw.
78 Nut.
94 Steering stop.
110 Plug.
79 Thrust bearing.
95 Screw.
111 Circlip.
80 Screw.
96 Pin.
112 Cover.
81 Nut.
97 Grease nipple.
113 Rear flange.
82 Screw.
98 Screw.
114 Lock screw.
99 Seal.
115 Nut.
83 Cylinder pin. 84 Cylinder.
100 Bush.
116 Torsion bar.
85 Circlip.
101 Bush.
117 O-ring.
86 Washer.
102 Washer.
118 Pin.
87 Seal.
103 Seal.
119 Seal.
88 Washer.
104 Nut.
120 Washer.
89 Grease nipple.
105 Seal.
121 Bush.
90 Washer.
106 Front flange.
122 Seal.
91 Seal.
107 Screw.
92 Hydraulic coupling.
108 Bush.
Removing/refitting the suspension cylinder 20.25 SI – Immobilise the tractor (see "Preliminary operations prior to working on the front axle"). – Sling the assembly on the level of the wheel pivot. – Remove the axis (48), (see removal of the upper arm 20.25 SI). – Remove the axis (96), (see removal of the lower arm 20.25 SI)
43
– Clear access to the lower part of the jack by lifting the assembly.
48 93
– Remove the circlip (93).
84
– Remove the lower part of the jack using a puller. – Proceed identically for the upper part after removing the stop ring (85). – To refit, apply the reverse sequence of removal.
96 452msm99
Arion 640-510 – 12.2008 – GB
121 Fig. 40
D2.31
