PROBLEM Fuel gauge sticks during operation or is inoperative.
THINGS TO DO 1. Slightly loosen nuts holding back clamp and check operation. Make sure gauge now operates properly and is not loose in panel. 2. Make sure battery is properly connected and ignition switch is on. 3. Check ground connection. 4. Contact your Alumacraft dealer.
PLUMBING Pump runs but fails to function.
1. Make sure applicable valves are open. 2. Remove pump filter screen and inspect for clogs. Remove clogs and restart pump. Make sure pump impeller works and re-assemble unit. 3. Check input and output hoses for blockage and remove any clogs. 4. Contact your Alumacraft dealer.
MARINE WIRING COLOR CODE RED BLACK PURPLE GRAY GRAY/WHITE BROWN BROWN/WHITE BLUE GREEN YELLOW/RED PINK BROWN/RED BROWN/BLUE ORANGE/WHITE ORANGE PURPLE/RED
76
Main power feed, 2V positive Common ground, 12V negative Ignition keyed power feed Fuse to stern light, tach sender Fuse to bow light Fuse to bilge pump Fuse to aerator pump Interior courtesy lights Fuel system bond wire Starting circuit Fuel sender to gauge Recirculating pump Recirculating pump Horn Accessory Radio
