! WARNING
Drive System
Make sure the ATV is solidly supported on the support stand to avoid injury.
SPECIAL TOOLS A number of special tools must be available to the technician when performing service procedures in this section. Refer to the current Special Tools Catalog for the appropriate tool description. Description
2. Engage the brake lever lock; then remove the wheels. 3. Remove the hub caps; then remove and discard the cotter pins.
p/n
Pivot Lock Nut Wrench
0444-201
Rear Axle Nut Wrench
0444-198
Pinion Gear Bearing Nut Wrench
0444-203
Pinion Puller
0444-202
V Blocks
0644-535
NOTE: Special tools are available from the Arctic Cat Service Parts Department.
Rear Drive Assembly Schematics
KM464
4. Remove the rear wheel hubs; then remove the brake caliper and lay aside. NOTE: Do not apply pressure to the brake pedal with the caliper removed. The brake piston will be pushed out and brake fluid will be spilled.
DVX
5. Remove the two axle nuts (left-hand threads). Account for one flat washer and a spacer.
KM462
Utility
KM471
6. Remove the brake disc assembly from the axle.
KM463
Rear Drive Axle (DVX) REMOVING 1. Secure the ATV on a support stand to elevate the rear wheels. 84
