3. Remove the choke assembly from the carburetor leaving the choke cable attached to the choke plunger.
Fuel/Lubrication/Cooling .
Carburetor
KC0018
4. Remove the screw securing the throttle actuator cover to the carburetor; then remove the cover.
KEY 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12.
Screw Top Spring Seat, Spring Jet Needle Vacuum Piston Needle Jet Needle Jet Holder Main Jet Starter Valve Coil Spring Cap
13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24.
O-Ring Cable Tube Pilot Screw O-Ring Float Arm Pin Float O-Ring Slow Jet Drain Screw Float Valve Float Valve Clip
25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36.
Float Chamber Screw Clip Drain Tube Spring Washer Washer Spring Idle Adjust Screw Top Cover Screw Starter Jet
PR154B
5. Remove the throttle cable from the actuator arm.
0742-556
! WARNING Whenever any maintenance or inspection is performed on the fuel system during which there may be fuel leakage, there should be no welding, smoking, open flames, etc., in the area.
REMOVING 1. Remove the seat; then remove the gas tank (see Gas Tank in this section). 2. Remove the cap screws securing the air filter housing to the frame; then loosen the clamp securing air inlet boot to the carburetor and remove the air filter.
PR162C
6. Loosen the outer jam nut securing the throttle cable to the carburetor body; then route the cable out of the way.
KM320A
64
