ForTractorsAfterSerialNumber1268128
DOWNLOAD OPERATOR MANUAL
FEDERALEMISSIONSWARRANTY
(Californiaownerísemissionswarrantyiscoveredelsewhere)
NewHollandwarrantsthatyournew1996andlaterheavy-dutyoff-roaddieselenginewasdesigned,built,andequippedtoconformtoapplicable U.S.EnvironmentalProtectionAgencyregulationsforaperiodofuseoffiveyearsor3,000hoursofoperation,whicheveroccursfirst.
Thenewmodelyear,classofdieselengine,andemissionapplicationdeterminationforyourengineareidentifiedontheemissioncontrol informationlabelaffixedtothetopofyourengineísrockerarmcover.Thewarrantyperiodbeginsonthedatethenewequipmentissoldtothefirst retailpurchaser.
Anyemissioncontrolsystempartswhichareprovendefectiveduringnormalusewillberepairedorreplacedduringthewarrantyperiod.The warrantyrepairsandservicewillbeperformedbyanyauthorizedNewHollanddealeratthedealerísplaceofbusiness,withnochargeforpartsor labor(includingdiagnosis).
Astheengineowner,youareresponsibletoperformalltherequiredmaintenancelistedinyourownerísmanual.NewHollandwillnotdenyan emissionwarrantyclaimsolelybecauseyouhavenorecordofmaintenance;however,aclaimmaybedeniedifyourfailuretoperform maintenanceresultedinthefailureofawarrantedpart.Receiptscoveringregularmaintenanceshouldberetainedintheeventofquestionsand thesereceiptsshouldbepassedontoeachsubsequentowneroftheengine.
ItisrecommendedreplacementpartsusedformaintenanceorrepairsbeNewHollandServicePartstomaintainthequalityoriginallydesigned intoyouremissioncertifiedengine.Theuseofnon-NewHollandpartsdoesnotinvalidatethewarrantyonothercomponentsunlesstheuseof suchpartscausesdamagetowarrantedparts.
NewHollandwishestoassuretheemissioncontrolsystemswarrantyisbeingproperlyadministered.Ifyoubelieveyouhavenotreceivedthe serviceentitledtounderthiswarranty,youshouldcontactthenearestNewHollandBranchOfficeforassistance.Theaddressandphone numberofeachBranchOfficeisinyourvehicleownerísmanual.Ifadditionalassistanceorinformationisneeded,contact:
ServiceDepartment NewHollandNorthAmerica,Inc. 500DillerAvenue NewHolland,PA17557 (717)355-1121
PleasenotethattheEmissionWarrantydoesnotcover:
1.SystemsandpartsthatwerenotfirstinstalledonthenewequipmentorengineasoriginalequipmentbyNewHolland.
2.Partmalfunctionscausedbyabuse,misuse,improperadjustment,modification,alteration,tampering,disconnection,improperor inadequatemaintenance,oruseofnon-recommendedfuelsandlubricatingoils.
3.Accidentcauseddamage,actsofnature,orothereventsbeyondNewHollandíscontrol.
4.Replacementofexpendableitemsmadeinconnectionwithscheduledmaintenance.
5.Partsrequiringreplacement,inspectionoradjustmentmaintenanceintervalsforreasonsotherthanbeingdefective.
6.PartswhicharenotNewHollandServiceParts.
7.Lossoftime,inconvenience,lossofuseofequipment/engineorcommercialloss.
8.Equipmentwithalteredordisconnectedhourmeterwherethehourscannotbedetermined.
9.EquipmentnormallyoperatedoutsidetheUnitedStates.
10.Non-defectivepartsreplacedbyotherthanNewHollanddealers.
Coverage
Thisemissioncontrolsystemwarranty appliestothefollowingemissioncontrolparts.
FuelInjectionPump
FuelInjectors
Turbocharger
IntakeManifold
ExhaustManifold
BoostPressureTubing-connectiontoAneroidDeviceONF.I.P.
CALIFORNIAEMISSIONCONTROLWARRANTYSTATEMENT
YourWarrantyRightsandObligations
TheCaliforniaAirResourcesBoardandNewHollandarepleasedtoexplaintheemissioncontrolsystemwarrantyonyour engine.InCalifornia, new1997andlaterheavy-dutyoff-roadenginesfrom100to150HPmustbedesigned,built,andequippedtomeettheStateísstringentanti-smog standards.NewHollandmustwarranttheemissioncontrol systemonyour enginefortheperiodsoftimelistedbelow,providedtherehasbeenno abuse,neglect,orimpropermaintenanceofyourengine.
Youremissioncontrolsystemincludespartssuchasthefuelinjection systemandtheairinduction system.
Whereawarrantableconditionexists,NewHollandwillrepairyourheavy-dutyoff-roadengineatnocosttoyou,includingdiagnosis,parts,andlabor. ManufacturerísWarrantyCoverage:
The1997andlaterheavy-dutyoff-roadenginesarewarrantedfromtheoriginaldateofdeliveryforfiveyearsor3,000hoursofoperation, whicheveroccursfirst.Ifanyemission-relatedpartonyourengineisdefective,thepartwillberepairedorreplacedbyNewHolland.
OwnerísWarrantyResponsibilities:
D Astheheavy-dutyoff-roadengineowner,youareresponsiblefortheperformanceoftherequiredmaintenancelistedinyourownerís manual.NewHollandrecommendsthatyouretainallreceiptscoveringmaintenanceonyourheavy-dutyoff-roadengine,butNewHolland cannotdenywarrantysolelyforthelackofreceiptsorforyourfailuretoensuretheperformanceofallscheduledmaintenance.
D Astheheavy-dutyoff-roadengineowner,youshould,however,beawarethatNewHollandmaydenyyouwarrantycoverageifyour heavy-dutyoff-roadengineoraparthasfailedduetoabuse,neglect,impropermaintenance,orunapprovedmodifications.
D Yourengineisdesignedtooperateoncommerciallyavailabledieselfuelonly.Useofanyotherfuelmayresultinyourenginenolonger operatingincompliancewithCaliforniaísemissionsrequirements.
D Youareresponsibleforinitiatingthewarrantyprocess.TheARBsuggeststhatyoupresentyourheavy-dutyoff-roadenginetoaNew Hollanddealerassoonasaproblemexists.Thewarrantyrepairsshouldbecompletedbythedealerasexpeditiouslyaspossible.
Ifyouhavequestionsregardingyourwarrantyrightsandresponsibilities,youshouldcontactyourBranchOfficeattheaddressandphonenumber listedontheOwnerAssistancepageofyourequipmentsoperatormanual.
D Priortotheexpirationofthewarranty,youmustgivenoticeofanyfailureofanemissioncontrolwarrantedpart.Suchnoticemustbegivento NewHollandoranauthorizeddealer,andyoumustdelivertheenginetotherepairlocation.
D You,theowner,areresponsibleforincidentalcostsincurredbyyourselforyouremployeesasaresultofawarrantablefailure.Examplesof suchcostsarecommunicationexpenses,mealsandlodging.
D Theownerisresponsibleforanybusinesscostsorlosses,anyìdowntimeîexpensesandanyìcargoîdamagewhichresultfromthefailure ofawarrantedpart.NewHollandisnotresponsibleforotherincidentalorconsequentialdamages,includingbutnotlimitedtofines,theft, vandalismorcollisions.
Partscovered:
Thisemissioncontrolsystemwarranty appliestothefollowingemissioncontrolparts.
FuelInjectionPump
FuelInjectors
Turbocharger
IntakeManifold
ExhaustManifold
BoostPressureTubing-connectiontoAneroidDeviceONF.I.P.
Anyreplacementpart,equivalentinperformanceanddurability,maybeusedintheperformanceofanymaintenanceorrepairsandmustbe providedwithoutchargetotheowner.TheuseofthesepartsdoesnotreducethewarrantyobligationsofNewHolland.However,NewHolland recommendstheuseofnew,genuineNewHollandservicepartsorNewHollandapprovedrebuiltpartsandassemblies.NewHollandalso recommendsthattheenginebeservicedbyaNewHollandauthorizeddealer.
NewHollandResponsibilities
Warrantyworkwillbeprovidedatnochargetotheowneratanyauthorizeddealer,usingnewgenuineNewHollandservicepartsorNewHolland approvedrebuiltpartsorassemblies..
Theownerwillnotbechargedfordiagnosticlaborwhichleadstothedeterminationthatawarrantedpartisdefective,ifthediagnosticworkwas performedatawarrantystation.
NewHollandisliablefordamagestootherenginecomponentscausedbythefailureunderwarrantyofanywarrantedpart.
WarrantyLimitations
NewHollandisnotresponsibleforfailuresresultingfromabuseorneglectbyowneroroperator.
NewHollandwarrantstotheultimatepurchaserandeachsubsequentpurchaserthattheengineisdesigned,built,andequippedsoastoconform withallapplicableregulationsadoptedbytheAirResourcesBoard,andthatitisfreefromdefectsinmaterialsandworkmanshipwhichcausethe failureofawarrantedpart.
Anywarrantedpartwhichisnotscheduledforreplacementasrequiredmaintenance,orwhichisscheduledonlyforregularinspectiontotheeffect ofìrepairorreplaceasnecessaryîiswarrantedforthewarrantyperiod.
Anywarrantedpartwhichisscheduledforreplacementasrequiredmaintenanceiswarrantedfortheperiodoftimepriortothefirstscheduled replacementpointforthatpart.
NewHollandisliablefordamagestootherenginecomponentscausedbythefailureunderwarrantyofanywarrantedpart.
CALIFORNIA
Proposition65Warning
Dieselengineexhaustandsomeofitsconstituentsareknown totheStateofCaliforniatocausecancer,birthdefects,and otherreproductiveharm.
Batteryposts,terminalsandrelatedaccessoriescontainlead andleadcompounds,chemicalsknowntotheStateof Californiatocausecancerandbirthdefectsorother reproductiveharm.Washhandsafterhandling.
TOTHEUSER
GENERAL
ThisUseandMaintenanceManualprovidesaguide fortheuserwithregardtorunning--in,useand maintenanceofthetractor.
Readthismanualcarefullyandkeepinaconvenient placeforfuturereference.Donothesitatetocontact yourlocaldealerforanyquestionsconcerningthe tractor.Thedealercanprovideskilledpersonnel, trainedbytheManufacturer,originalsparepartsand alltoolsandequipmentnecessaryforyourservice requirements.
SAFETY
Safetyprecautionsfortheoperatorandbystanders areshownonpagesviitoxiiiinclusive.Readthe safetyinstructionsandfollowrecommendationsand hints before startingtousethetractor.
SERVICEAFTERTHEFIRST50HOURSOF WORK
Theoperationsrequiredforthefirstserviceare shownattheendoftheManual,immediatelypriorto theindex.
Thetractorisdesignedasapowergeneratorand drive--propulsionunitforuseinnormalandtraditional agriculturalconditions.
Thetractorisalsodesignedtoprovidemaximum performance,economicrunningandeasyuseovera widerangeofoperations.Priortodelivery,all machinesarecarefullyinspected(byboththe Manufacturerandyourlocalauthoriseddealer),to makesurethattheyreachtheuserinperfect condition.Tomaintainthetractorinthisconditionand ensuretrouble--freeoperation,theroutine maintenancedescribedinSection3ofthismanual mustbecarriedoutatthespecifiedintervals.
CLEANINGTHETRACTOR
Yourtractorisanadvancedmachine,fittedwithan electro--hydrauliccontrolsystem.Careshouldbe takenwhencleaningthetractor,especiallyifa pressurisedwatercleanerisused.
• Neverstandtooclosetothetractorordirectthe waterjetonelectricalcomponents,sealsor intakeopenings,etc.
• Neverdirectjetsofcoldwateratthehotengine orexhaust.SeealsoSection3 (Recommendationsforbodyworkmaintenance).
Afterthefirst50hoursofuse,returntothedealerwith yourtractorandthisManualinordertocarryoutthe Manufactureríschecksandtofillinthecertificates includedonpages(1and3).Thefirstsheet(page1) mustbecompiledoncompletionoftheserviceand heldbythedealer.Thesecondsheet(page3)must bekeptintheManualfordocumentationand referencepurposes. Checkthatbothcopiesare signedbybothyourselfandthedealer.
SPAREPARTS
ìNon--originalîsparepartshavenotbeentestedor authorisedbytheManufacturer.Instalmentand/or useofsuchproductsmayadverselyaffectthe tractorísdesignspecifications,thereby compromisingoperationalsafety.Themanufacturer cannotbeheldresponsibleforanydamageresulting fromtheuseofìnon--originalîspareparts. Nomodificationsmaybemadetothetractorwithout writtenauthorisationfromtheManufacturer.
WARRANTY
Thetractorisguaranteedinaccordancewithcurrent legislationinyourcountryandinlinewithcontractual agreementsreachedwiththedealeratthetimeof sale.However,thewarrantyisnolongervalidifthe rulesandinstructionsfortheuseandmaintenance ofthetractor,describedinthisManual,arenot observe
TRACTORIDENTIFICATION
Serialnumbersand/orproductioncodesidentifythetractoranditsmaincomponents.Theidentificationdata mustbesuppliedbythedealerforrequestsforsparepartsorserviceoperations.Identificationdataisof fundamentalimportanceintheeventoftheftofthetractor.Thelocationofthevariousidentificationdataisshown below.
Frameidentificationdataplate. (InsideofROP)
Engineidentificationdataplate
Frameandenginetypeidentification dataplate.(InsideRRFender)
Tractorframenumberidentification dataplate(stampedontheaxlesupport underthebonnet).
IMPORTANTECOLOGICAL CONSIDERATIONS
Soil,airandwaterareessentialelementsfor agricultureandforlifeingeneral.Iflocallegislation doesnotcontrolthetreatmentofcertainsubstances, theproductionofwhichisnecessitatedbyadvanced technologies,productsderivedfromchemicaland petrochemicalproductsmustbeusedanddisposed ofaccordingtotherulesofcommonsense.
Thefollowingrecommendationsmaybeofhelp:
• Findoutwhattherelevantlegislationstipulates.
• Askyoursuppliersoflubricants,oils,fuels, anti--freeze,detergents,etc.,forinformationonthe effectsoftheseproductsonhumansandthe environmentandforinstructionsconcerningtheir use,storageanddisposal.Inmanycases,local agriculturalconsultantswillbeabletoprovide assistance.
SUGGESTIONS
1.Avoidusingunsuitable,pressurisedfilling systemsorfuelcanswhenfillingtanks,asthese maycauseconsiderablespillageandleakageof liquids.
2.Asageneralrule,donotallowliquidfuels, lubricants,acids,solvents,etc.,tocomeinto contactwiththeskin.Themajorityofthese productscontainsubstancesthatarepotential healthhazards.
3.Modernlubricantscontainadditives.Donotburn contaminatedfueloilsand/oroilsusedin conventionalheatingsystems.
4.Avoidspillagewhentransferringusedengine coolingliquids,engineandtransmission lubricants,hydraulicoils,brakefluids,etc.. Nevermixusedbrakeoilwithfueloil,orfueloil withlubricants.Storesafelyuntilsuitable disposalcanbearrangedaccordingtonational legislationorlocalregulations.
5.Modernanti--freezeliquidsandsolutions,e.g.: anti--freezeandotheradditives,mustbe replacedeverytwoyears.Theymustnotbeleft tobeabsorbedintotheground,butmustbe collectedanddisposedofinasuitablemanner.
6.Donotopentheairconditioningsystemstocarry outwork.Thesesystemscontaingaswhichmust notbereleasedintotheatmosphere.Contactyour dealerorspecialisedpersonnel,whoareequipped withtheappropriateequipmentandareauthorised tore--fillthesystem.
7.Anyleakageordefectintheenginecoolingor hydraulicsystemsmustberepairedimmediately.
8.Donotincreasethepressureinpressurised systems,asthismaycausecomponentpartsto burst.
9.Whenwelding,makesurethathosesare properlyprotectedassparksormoltenmaterial maypunctureorweakenthetubesandsleeves, resultinginleakageofoil,coolingliquid,etc..
10.Donotadjustthesettingofthefueldelivery systemasthiswillaltertheemissionofexhaust fumes.
NOTE: Theenginesinstalledonthetractorscomply withanti--pollutionlegislation.
ALWAYSWORKSAFELY
IMPORTANTWARNINGS
Themachineisdesignedandproducedexclusively foragriculturaluse.
Thissymbolisusedtoalertthereadertoimportant informationwhichdirectlyconcernspersonalsafety.
Readthefollowingsafetyinstructionscarefullyand followtherecommendationsinordertoavoid potentialhazardsandsafeguardyourhealthand safety.
Inthetextofthismanualyouwillfindthesymbol alongsidethefollowingkeywords:
CAUTION --Whenthewarningistopreventpotential damagetothemachine,whichcouldalsoputthe operatoríssafetyatrisk.
DANGER --Thiswarningspecificallyindicatesa potentialdangertotheuserortoanyotherperson directlyinvolved.
Failuretoobservetheinstructionsprecededbythe aforementionedkeywords(CAUTION and DANGER )mayresultinsevereorfatalinjurytothe personsinvolved.
Furthermore,thismanualalsocontainsinstructions initalicsprecededbytheterms NOTE and WARNING ,withthefollowingrelevanceinrelationto machineprotection:
NOTE -- Underlinesthecorrectprocedureor techniquetobefollowedbytheoperator.
WARNING -- Informstheoperatorofthedangerof damagingthemachineifthespecifiedprocedureis notfollowed.
Allotherusewillbeconsideredtobecontrarytothe usespecifiedbyNEWHOLLAND,whocannotbe heldliablefordamagetopropertyorthemachine,or forpersonalinjurieswhichmayresult.
Personswhoriskimproperusewillthereforeassume theresponsibilityforanyconsequencesarisingfrom suchuse.
Compliancewiththeinstructionsforuse,maintenance andrepairsdescribedinthismanual,aretheessential preconditionsfortheusespecifiedbyNEW HOLLAND.
Themachinemustonlybeused,servicedorrepaired bypersonneltrainedintherelevantworkingmethods andsafetyregulationsandwhohavebeen authorisedtoworkonthemachine.
Theusermustalsoobservetherulesconcerning generalsafetyandaccidentprevention,includingthe HighwayCodewhendrivingonpublichighways.
Anyarbitrarymodificationsmadetothismachinewill releaseNEWHOLLANDfromanyliabilityresulting fromdamageorinjury.
NEWHOLLANDandalldistributionorganisations, inclusiveof,butnotrestrictedto,national,regionalor localdistributors,cannotbeheldliablefordamage resultingfromthemalfunctionofpartsand/or componentsnotapprovedbyNEWHOLLAND.
Undernocircumstanceswillaguaranteebeissued forproductsmadeorsoldbyNEWHOLLANDthat aredamagedasaresultofthemalfunctionofparts and/orcomponentsnotapprovedbyNEW HOLLAND.
GENERAL
Duringthemanufacturingofthistractor,everystep hasbeentakentoensuresafeoperation.However, thebestwaytoavoidaccidentsistoexercisecaution atalltimes.Oncetheaccidenthasalreadyhappened itistoolatetorememberwhatstepsshouldhave beentaken.
Itisadvisabletokeepafirstaidkitonhand.
Readthismanualcarefullybeforestarting,using, carryingoutmaintenance,refuellingorperforming anyothertypeofoperationonthetractor.
Thetractormustonlybeusedbyresponsiblepersonnel,trainedintractoruseandauthorisedtooperatethemachine.
Thetimespentreadingthismanualwillallowyoutoget toknowyourtractor,therebysavingtimeandeffort.. Thiswillalsohelppreventaccidentsfromtakingplace.
Donotaltertheinjectionsystemcalibrationinanattempttoincreasemaximumenginespeed.
Readallthesafetydecalsonthemachineandfollow theinstructionsthereonbeforestarting,operating, refuellingorcarryingoutmaintenanceonthemachine.Promptlyreplaceanydecalsthataredamaged,lostorillegible.
Cleanthedecalsiftheyarecoveredbymudordebris.
Rememberthatthetractorisexclusivelydesigned foragriculturaluse.Anyotherusewillrequireprior authorisationfromNEWHOLLAND.
Donotwearlooseclothingthatmaybetrappedinmovingparts.
Checkthatallrotatingpartsconnectedtothepower take--offarecorrectlyprotected.
SAFETYNORMS
Donotalterthecalibrationofthepressurerelief valvesinthevarioushydrauliccircuits(hydrostatic steering,hydrauliclift,auxiliarydistributors,etc.).
Avoidusingthetractorinunsuitablephysicalconditions,stopworkinstead.
Enterandleavethetractorusingthestepsand handlesprovided.Keepthesefittingsfreeofmud anddebris.
Alwaysoperatewiththerollbarcorrectlyandsecurelyfittedonthetractor:periodicallycheckthatthefittingsarenotlooseandthatallpartsofthestructure arefreefromanydamageanddeformation.Donot modifytherollbarbyweldingparts,drillingholes, etc.,asthiscouldadverselyaffecttherigidityofthe structure.
STARTINGTHETRACTOR
Beforestartingtheengine,checkthatthehandbrake isonandthatthegearsandpowertake--offaredisengaged,evenifthetractorisfittedwithastart--up safetydevice.Neverdisconnectthestart--upsafety switch.Iftheswitchdoesnotworkcorrectly,contact yourlocaldealerforeventualrepairoperations.
Beforestartingtheengine,makesurethatallattachedimplementsareloweredtotheground.
Beforestartingtheengine,checkthatallcoversand guardsarecorrectlyinposition(rollbar,engineside panels,powertake--offguard,frontaxletransmissionshaftcover,etc.).
Neverstartormaneuverthetractorunless seatedinthedrivingposition.
Beforemovingthetractor,alwayscheckthatthe areaisfreeofpeopleorobstacles.
Neverruntheengineinaclosedspacewithoutensuringadequateventilation.Exhaustfumesaredamaging tothehealthandcanbelethal.
Selectthemostsuitablewheelsettingfortheworkin hand,i.e.:thesettingthatprovidesthebeststability.
Whenthetractorismoving,theoperatormustremaincorrectlyseatedinthedrivingposition.
Nevergetonoroffthetractorwhileinmovement.
Whenusingthebrakes,pressthepedaldownslowly.
Avoidcurvingathighspeeds.
Engagetheclutchslowly:ifengagedtooquickly,especiallywhenthetractorisgettingoutofahole,ditch oroperatingonmuddygroundorsteepslopes,the tractormayoverturn.
Releasetheclutchimmediatelyifthefrontwheelsstart tolift.
Alwaysusethetractorataspeedthatwillguarantee safeoperationonthetypeoflandbeingworked. Whenworkingonunevenground,usemaximum caretoensureproperstability.
Ifyouhavetoworkwiththetractoronaincline,for exampleonhillsides,driveatmoderatespeedespeciallywhentakingcurves.
Whentravellingdownhill,keepthetractoringear. Neverreleasetheclutchandneverleavethegears inneutral.
Proceedwithmaximumcautionwhenworkingwith thewheelsneartheedgeofditchesorslopes.
Whendrivingonpublichighways,observetheHighwayCode.
