INNOVATIVE TECHNOLOGIES AS CATALYSTS FOR THE

TRANSITION TO SUSTAINABLE ENERGY PRODUCTION

TRoland Gruber Editor-in-Chief | rg@zek.at

he media’s response was rather weak and restrained. Only a few publications even considered it worth a headline: as of the beginning of this year, the global average temperature has exceeded the 1.5 °C mark. That’s the mark that was established at the Paris Climate Conference in 2015, as agreed to by the representatives of 195 countries. This means we are talking about a historical event of the deplorable kind, with incalculable consequences. However, resignation or defeatism are not an option. After all, this crucial development has the potential of accelerating the efforts of the growing climate tech industry. As Jan Lozek, the founder of Future Energy Ventures, recently pointed out with decided optimism, “Crossing that 1.5-degree threshold might, paradoxically, turn out to be just the kind of catalytic event the climate tech industry needs right now. That’s because it highlights the urgency for further investments in climate technologies and opens up new markets for adaptive solutions.” In this respect, Lozek shares an opinion voiced by many other energy experts in the field: AI may well turn out to be the key to the ‘energy turnaround’, as it is already emerging as a major factor in integrating and optimising decentralised energy sources, ready to boost the overall efficiency of our electricity grids. A successful transformation of the energy supply system also depends on modern high-capacity grid structures – and increasingly on AI-driven controls capable of adjusting automatically to the behavioural patterns of providers and consumers alike. In all of this, research and development play a central role, as does the systematic knowledge transfer between the fields of research and its practical application. The technical solutions that will lead us towards a post-fossil future of energy are opening up vast economic opportunities – especially considering Europe’s extensive technical competence in the energy sector. At any rate, one thing is clear: by far the greatest growth potential within the energy sector lies in renewable sources. The current World Energy Outlook expects the share of energy from renewables to grow from 30 per cent (as of 2023) to 83 per cent by 2050. For Europe, the projected share is even 84 per cent. In the long run, photovoltaics and wind power may well be the main drivers of growth across the industry. However, hydropower will remain an indispensable player where sustainable energy production is concerned – especially in Central Europe. Today, this aspect is more important than ever, considering the vehemence and sometimes patently false or outdated arguments raised by hydropower opposers in many media channels. Hydropower is anything but a relic from a distant past. On the contrary, hydropower is being under constant further development by innovative providers, universities and other research institutions. With the resulting latest advancements in digital research raising the achievable level of performance, hydropower will continue to be an indispensable factor in ensuring a reliable supply of electrical energy. This was also confirmed in recent study put out by the Energy Watch Group, which called for a serious re-evaluation of hydropower’s frequently distorted public image. According to the study, modern re-powering efforts can be shown to help ensure a sustainable hydro-ecology and diversity of species. As the authors point out, the decline of the fish population is caused primarily by environmental toxins and high-levels of methane from agricultural sources. The study further shows that hydropower facilities are essential contributors to the removal of plastic waste and noxious biomass from the rivers. In a further conclusion the authors confirm that hydropower contributes crucially to grid stability. Moreover, the study also investigated the vehement call by several organisations for a “renaturation” of existing transverse structures. In fact, if this is done while maintaining the straightened course of a river, it will accelerate the velocity of flow, This, in turn, will deepen the water bed, thus lowering the subterranean water levels in the area around river banks and water meadows. It’s a classic example of “improving things for the worse”. Taken together, these arguments should provide more than sufficient reasons for government to ramp up their efforts towards more – and more sustainable – support for the (smallscale as well as large-scale) hydropower industry.

I wish all our valued readers an enjoyable and informative time reading the latest edition of zek HYDRO.

Best regards,

Roland Gruber [Editor-in-Chief]
