V.I.N.: 7A9AS0521RH002059
TARE WEIGHT 9900kg
ATM 36,000kg
GTM (trailer closed) 21,000kg
GTM (trailer fully widened) 15,000kg
FORWARD LENGTH 9.5m
REAR OVERHANG: 2.7m
DECK LENGTH: 9530MM
WIDTH: 2 49m closed – 3.55m fully open
DECK RIDE HEIGHT: 470mm
SUSPENSION: AIR
Major components of this trailer are made from GRADE 80 High Tensile steel, PREHEATING BEFORE WELDING is essential to avoid post welding cracking.
Please contact TRT for welding procedures and consumable specifications before welding.
TRT NZ 1800 802 912 07 849 4839
Brennan Rietema Design Engineer
Nick Marsh Workshop Foreman
Failure to contact TRT to gain the proper weld procedure could cause additional failures and may result in the warranty being voided.
Do not pressure wash brake valves or electrical components
1. Park on level ground with enough clearance behind the trailer to drive or winch the load onto the trailer. Check the trucks air gauges to ensure the trailer is fully charged with air. Apply the park brakes, turn the PTO on and ensure the truck lights are turned on (The remote control is powered by the trucks lighting circuit and needs air to actuate the valves)
2. Go to the rear of the trailer to observe that the trailer is on level ground. Release the ramp chains while you are there
3. Remove the wood blocks from the rear of the ramp and place them under the back bumper, then lower the trailer onto the blocks using the ‘Suspension Valve’ at the rear of the top deck. When the trailer is on the blocks move the suspension valve to the HOLD position.
4. Can the load fit between the suspension pods.
Yes - it is wide enough to load Go to #7 NO - it needs to be widened Go to #5
5. Go to the rear of the trailer and use the remote controll to widen the trailer out fully. (When the trailer is widening try to keep the suspension pods parallal to each other)
6. When both sides are fully widened, lower the ‘in-fill decks’
7. Lower the ramp using the ramp control valve under the left rear of the top deck. When the ramp is fully lowered, PUSH the ramp valve handle over the detent to put the pamp into ‘float mode’ Check that the ramp tip is sitting flat on the ground. If it is not supported across its width the trailer needs to be moved to flatter ground.
8. Assess the load. - Will it drive on to the trailer safely using its own power?
YES I can drive the load onto the trailer
Go to #9
NO The load will need to be winched onto the trailer Go to #10 - Winch use
9. Drive the Load on to the trailer and tie down the load to the trailer.
10. WINCH operation
If the load is disabled or cannot be safely driven onto the trailer (insufficient or non-operational brakes…) the winch can be used to pull the load onto the trailer.
1. Activate the ‘Free-spool’ valve to release the winch brake. (This allows the winch rope to be manually pulled out.) Pull out the rope and fix the end to the load at a safe and strong recovery point.
2. Turn the free-spool off and operate the ‘winch IN’ function on the remote to pull the load onto the trailer. When the load is in the correct position, tie the load to the trailer.
3. Release the pull on the winch by winching out briefly
NOTE: you can leave the winch attached, but the load MUST be held to the trailer by its tiedown chains / Strops and not restrained by the winch
Has the trailer been widened.
YES But the load is now forward and I can close the trailer
YES But I need the trailer to remain widened
NO - - - -
Go to #11
Go to #13
Go to #13
11. Raise the ramp and secure it using the restraint chains then raise the in-fill decks and bring the suspension pods back in to their travel position.
12. Lift the ‘In-fill decks then bring the suspension pods back into their closed position.
13. Rise the trailer by putting the suspension valve back in TRAVEL mode. When the trailer has lifted off the wood blocks, return the blocks to their travel positions in the ramp.
14. Return to the truck and turn OFF the PTO
15. Release the brakes then move off slowly. The air suspension may still be raising to its final travel position.
On each occasion prior to using the transporter the following procedures must be carried out, to ensure the safe operation of the transporter and the safety of the personnel involved:
• Ensure that the maintenance schedule is up to date
• Walk around the trailer to check for obvious faults such as:
- Tyres are all correctly inflated including the spares
- Wheel nuts and studs are tight with none missing
- No air leaks from hoses, tanks, valves or couplings
- No hydraulic leaks from rams, hoses or valves
- No structural cracks to chassis
- Wheel alignment is correct
• Check that the trailer kingpin is the correct size and is fully engaged with the 5th wheel and that all of the hydraulic, electric and air couplings are fitted correctly.
• Test that brakes and lights are fully operational.
• Ensure that load security devices, which will be required, are carried. This means dunnage and matting. These are to be stowed securely to prevent movement while travelling.
• Check that you have the required permits to cover the load intended.
• Check that the suspension is set to the correct height
• Check that the route has adequate ground clearance to that which the trailer has available. This is particularly important over railway lines and off road situations.
• Allow for road traction, which is significantly reduced, in wet or unsealed conditions.
• Be aware of weather conditions as these can affect the load. Rain and Fog can reduce traction, increase stopping times and reduce visibility. High winds may affect the stability of the load. Hot conditions can increase tyre pressures and build up heat in the hub bearings
The air suspension is equipped with a ride height valves mounted on both sides of the rear axle ‘cassettes’ A docking valve is fitted on the Right side of the gooseneck to allow raising and lowering of the trailer.
Lowered position
Ride Height
The air is exhausted from all the air bags and the trailer will sit down on the axle stops. This is mainly for loading of plant onto the trailer.
The predetermined travel height position for the trailer. The trailer should always be set in this position when travelling. This position ensures that the axles will always be fully compensating for the load.
Raised Position Trailer air bags are inflated to raise the deck height
CAUTION:
When raising or lowering the suspension, the trailer will move backwards and forwards respectively. Never perform this operation while the trailer is resting on the landing legs as this may collapse the legs.
• Ensure that the trailer is on a flat even surface and there is at least 8 metres of clear space behind the trailer for loading when using the ramp. The surface behind the transporter should not be lower than the transporter wheels or you may damage the ramp.
• Place the trailer brakes in the parked position.
• Ensure the PTO is engaged, and the truck motor is running
• Place dunnage blocks under rear chassis beavertail both sides. The two blocks are located in Holders mounted to the rear of each widening cassette.
• Loosen and remove ramp chain binder.
• Lower the trailer suspension down onto the axle stops using the suspension control switch located on Right side of the gooseneck. (Leave in this position until load is secured.)
• Go to the ramp control valve (Left side of trailer at the rear of the top deck) and operate the lever to lower the ramp.
• Ramp float mode - Push lever, past the Down position, and over the detent, to put ramp in float mode.
• Load the equipment onto transporter and secure.
• Go to ramp control valve and operate the ramp lever to raise the ramp.
• Replace the ramp restraints and secure.
• Raise the suspension to travel position.
• Turn the PTO off
• NOTE: Always lower suspension before deploying ramps, otherwise damage to the ramp Hydraulic moto could occur.
When lowering the trailer, ensure there is no rocks or other hard objects under the chassis. CAUTION: Avoid point loading Chassis rails
Prior to loading you must understand the characteristics of the machine that is to be transported. If loading this yourself, you must have the relevant license or required expertise.
• Evaluate the following prior to loading:
- Machine weight
- Centre of gravity
- Width required to safely accommodate the track width with reference to the road conditions, terrain and stability.
- Final load position to comply with axle weights.
- Traction when loading over the ramps/beavertail. A winch may be required to load safely.
• Ensure that the transporter is on flat even ground and that you have sufficient space behind the transporter to load in a straight line. The loading operation must be protected from other traffic.
• Apply the truck and trailer brakes.
• Lower the trailer suspension.
• Remove the ramp securing chains and lower the ramps ensuring that no personnel or equipment are in the way. Leave ramp control in detented down position when loading or damage to ramp rams will occur. The ramps must be in full contact with the ground and bear evenly on each side of the transporter. When loading. The ramp valve must remain in the Detented FLOAT position.
• Load the machine according to manufacturer’s instructions. Care is to be taken at the apex of the beavertail, as the machine may become unstable. It may be necessary to use a winch to assist the loading at this stage. Position the machine to give the permitted axle loading.
• Secure the load as required by the Restraint of Load Regulations.
• Raise the ramp to the vertical position ensuring that they are clear of the load. The valve must remain in the mid-position once the operation is complete.
• Secure the ramp securing chain. Do not over-tighten.
• Raise the suspension back to ride height
• Check that the tyres are adequately inflated for the load on the transporter.
This trailer has a 16,000lb winch between the chassis rails at the front of the lower deck. The winch can be controlled either manually or by remote control
1. Start the PTO
2. Lower the ramps using the procedure on the previous page
3. Use the ‘Free-spool’ actuator to switch the winch into free-spool.
4. Manually pull the winch ramp out towards the load, far enough to secure the winch rope to a secure winching point.
5. Return tothe winch and switch the free-spool actuator backto winch mode.
6. PULL the winch valve handle to winch in.
7. When the vehicle is in place on the trailer, tie it down, raise the ramps and return the trailer to ride-height before moving off.
1. Follow the procedure above from 1-4 above for Manual Operation
2. When the powerpack Ignition is on, the remote receiver is also ON.
3. Use the WINCH IN and WINCH OUT buttons to control the winching direction. The Free-spool function is not on the remote.
NOTE: The transmitter requires a 9v battery to operate.
A Remote Controller power supply isolation switch is located on the enclosure under the left side top deck.
This trailer has the ability to be lifted or lowered and widen at the suspension modules. When the trailer is widened, 2 deck inserts need to be hydraulically lowered into the gaps left by the widening of the decks.
• The truck must be running and the PTO engaged.
• Lights must be on for the remote control to operate
• When operating the widening functions, keep the suspension modules parallel to the trailer
Widening the trailer
1. Place the dunnage blocks under the rear bumper and lower the trailer onto them. When the trailer is sitting on the blocks return the suspension control to HOLD mode.
2. Stand behind the trailer and operate the widening buttons on the remote to widen both suspension modules.
3. When they are fully widened, lower the ‘in-fill decks
Closing the trailer
1. Lift the in-fill decks up until they are against the suspension modules
2. Operate the remote buttons to close the trailer.
3. When it is fully closed, raise the suspension to ride height and replace the dunnage blocks in their travel brackets
4.
1. The procedure is the same except that the operator is using the manual control levers under the left rear of the top deck.
Daily
Operator to check
- Visual check for damage
- Check for air and / or hydraulic oil
- Drain air tanks
- Checks tires for wear and inflation
Two Weekly
- Check that tyre pressures are correct
- Check all lights operate
- Check that wheel nut torque values are correct
- Check brake adjustment and re-adjust as necessary
- Grease all grease points
- Ensure that skid plate has sufficient grease
- Wash trailer
Three Monthly
- As per two weekly check
- Check wheel bearing play and re-adjust as necessary
- Check brake shoe wear and replace as necessary
- Check wheel nut torque and wheel alignment
- Check S cam bushes for wear and replace as necessary
Six Monthly
- As per three monthly check
- Check tyre wear on all axles
- Rotate the tyres on all axles to ensure even tyre wear
- Check brake drum wear and replace as necessary
- Obtain C.O.F.
Twelve Monthly
- As per six monthly check
- Check wheel bearings
- Check S cams for wear and replace as necessary
- Replace drop out king pin as per regulations (For NZ trailers only)
- Replace wheel bearing grease – see wheel bearing section for maintenance and procedure
- Obtain new registration
BEFORE OPERATING TRAILER: King Pin must be amply greased with E.P. grease with MoS2 or graphite additive.
Sufficient greasing of King Pin and fifth wheel coupling is most important for the lifetime of both components.
NOTE: WHEEL NUTS MUST BE TORQUED AFTER THE FIRST 100km.
Central greasing location for each axle unit
SUSPENSION
AXLES
WHEELS (STEEL)
TYRES
HYD VALVE (Deck and Ramps)
HYD VALVE (Winch)
VALVE ACTUATORS (Air)
WIDENING CYLINDERS
RAMP DETENT KIT
AIR SOLENOIDS
DBL PILOT CHECK CARTRIDGES
HOSES AND FITINGS
REMOTE RECEIVER
RAMP ACTUATOR
WINCH ROPE
RELIEF CARTRIDGE (WINCH PULL)
LVO 22.5 x 11.75
385/65-R22.5
Q45m/7
Q45m/1
HYQ45P1N
TD248-010 2 x 1.25 x 219 Stroke
HY03750R10/Z1
AMSSA225-08
HYDC10-40
HYDRAULINK
ELMCR91516R
TRTR600-38
14mm 6x36 IWRC Galv
RV10-22-A-0-N-35
Part No. Description
RW2430SB
SPRING BRAKE TYPE 24/30 x6
WA4801020800 TEBS BRAKE KIT
SL17600B VALVE – YARD RELEASE
BX276785
AIR TANK 9.1 LTR
HE60502-000P HEIGHT CONTROL
HEA 14187
HE60502-000P
WA43450000340
HEA 14187
AMMVHA-41V 1/8
LINK KIT - RIDE HEIGHT VALVE
VALVE – RAISE LOWER
VALVE - SELECT LOW
LINK KIT - RIDE HEIGHT VALVE
AIR TOGGLE SWITCH – WINCH FREE-SPOOL
Part No.
HA4912 7 PIN SOCKET
HA2053 LED – SIDE MARKER
HA2074 LED - FRONT MARKER (CLEAR)
HA2301S LED REAR MARKER
HA 0990 LED - SIDE MARKER AMBER
HA2931 STOP / TAIL LAMP
HA2073 LED - SIDE MARKER
HA2919 REFLECTOR AMBER
HA1611 LED - BEACON
HA2559 LED - LICENSE PLATE
AM3540 JUNCTION BOX
HA2031 LED - OVAL SIDE MARKER AMBER
CIXT027/AR HAZARD SIGN
AMTDR08201 WORKLIGHTS
HA6042 REVERSING ALARM
