Mixquip Series 200 IBC Pallet Tank Mixer

MIXQUIP. YOUR PROCESS MATTERS

IBC BRIDGE MOUNT MIXING PORTABLE: SERIES 200

BLEND | DISPERSE | SUSPEND

National Call: 1300 649 784

www.mixquip.com | sales@mixquip.com

STATE-OF-THE-ART MIXING

ADVANTAGES » Cost effective mixing solution » Mix and ship in the same container » Additions funnel option helps add liquids/powders whilst mixing. » Mix to low levels within the IBC container » Wetted parts 316 stainless steel » Variable speed options » Adjustable clamp secures mixer to most IBCs » Convenient lift handles & fork lifting pockets MIXING SYSTEM

DESIGN

The Mixquip Rummager Series 200 is specifically designed to suit an IBC (intermediate bulk container) as a robust, versatile and adjustable mixing system. Just as IBC’s have taken over from 200L drums as safer and more cost-effective fluids transport containers, so has the Mixquip Rummager Series 200 mixer, revolutionised the mixing and processing of fluids, with a mix-in-the-box breakthrough, applicable to both thin liquids and thicker mixtures.

The Mixquip Rummager Series 200 mixing system is used to blend, disperse and suspend aterials within the IBC resulting in improved process times and business productivity.

OPERATION SEQUENCE

SPECIFICATIONS

MIXING OPTIONS Australian designed and manufactured Mixquip Series 200 IBC mixers are available with a wide range of drives, including pneumatic, 240Volt electric and three phase motors.

VARIABLE SPEED Both direct drive and gear drive units are available with variable speed drives for 240V and 415V.

AIR DRIVE ATEX applications can be safely handled with air drive motors.

ADDITIONS FUNNEL Powder and Liquid additions can be added to an IBC simply via the Mixquip additions funnel.

GEAR / DIRECT DRIVE 240V OR 3PH DIRECT DRIVE - Model S200SF is high-speed direct drive mixer suitable for low-viscosity fluids.

IMPELLER Direct drive units are available with superflo impellors. Gear drive units are supplied with folding Toro-Jet impellors.

MIXING SYSTEM

DESIGN

GEAR DRIVE - Model S200TJ is slow-speed gear drive mixer suitable for all range of

OPERATION SEQUENCE

SPECIFICATIONS

RIGID . ROBUST . RAPID

Designed to suit most IBC containers with its heavy-duty form and robust construction, the Series 200 mixer is ideal for demanding mixer applications.

Mixquip Series 200 Bridge Mounted IBC Agitators are ideal for a variety of applications such as blending, dispersing and suspending viscous liquids and high solid slurries, or wetting and dissolving powders.

APPLICATIONS » Bituminous emulsions

» Water Treatment/pH

» Flocculant Additions

» Honey

» Adhesive Manufacture

» Hand Sanitiser

» Shampoos & Conditioners » Polymer Mixing

» Liquid Fertiliser

NEED A MIXING SYSTEM OR HAVE SPECIAL PROCESS REQUIREMENTS? TELL US WHAT YOU NEED: 1300 649 784 | SALES@MIXQUIP.COM

FOOD & BEVERAGE

MIXING SYSTEM

CHEMICAL

DESIGN

PAINT & COATINGS

WASTEWATER

OPERATION SEQUENCE

PHARMACEUTICAL & VETERINARY

SPECIFICATIONS

MIXING PROCESS STAGE 1 The Toro-Jet impeller creates a toroidal flow pattern at the mix head as product material accelerates through the rotating cones. The action of the toroidal fluid movement creates both axial and radial fluid flow through the impeller.

STAGE 2

STAGE 3 WHY TORO-JET?

MIXING SYSTEM

DESIGN

» » » » » »

High viscosity mixing Mix to low tank levels Low tip speeds No product foaming Folding impellor design for IBC Works for all liquids from water, to honey

»

Blend/Disperse/Suspend

OPERATION SEQUENCE

SPECIFICATIONS

TECHNICAL SPECIFICATIONS

SERIES 200 PERFORMANCE CHARACTERISTICS SPECIFIC GRAVITY VERSUS VISCOSITY

Specific gravity (Kg/L)

1.5

1.2

1.1

[S200DD150SF]

1

[S200GD150TJ]

[S200DD075SF]

50

500

5000

[S200GD300TJ]

10000

Viscosity (Cps) *Performance guide only: Please contact our engineers if you have a specific duty.

MODEL DATA

Shipping Dimensions:

50cm x 60cm x

150cm Packed Weight: *Approximate

MIXING SYSTEM

75Kg

DESIGN

OPERATION SEQUENCE

SPECIFICATIONS
