SECTION 4: KNOW YOUR LAWN TRACTOR Compare the illustration in Figure 3 with the controls on your tractor; get familiar with these features before you start to operate the tractor. This manual covers two models. So follow the descriptions and instructions pertaining to your tractor model only.
E
A
F G B
H
+
1/10 P
P
I
J
C
K D
NOTE: Figure 3 A B C D E F
Systems Indicator Monitor/Hour Meter PTO (Power Take-off) Lever Choke Control (If equipped) Seat Adjustment Lever Throttle Control Lever Parking Brake Button
G H I J K
9
Cruise Control Button Ignition Switch Brake Pedal Drive Pedal Deck Lift Lever
Steering Wheel not shown for clarity.
