PERIODIC MAINTENANCE AND ADJUSTMENT decrease the clutch lever free play, turn the adjusting nut in direction (b). 7. Tighten the locknut at the clutch cable. 8. Tighten the locknut at the clutch lever, and then slide the rubber cover to its original position.
EAU37912
Checking the front brake lever free play
1. No brake lever free play
7
There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14211
WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system. If there is air in the hydraulic system, have a Yamaha dealer bleed the system before operating the vehicle. Air in the hydraulic system will diminish the
7-18
braking performance, which may result in loss of control and an accident.
