INSTRUMENT AND CONTROL FUNCTIONS EAU46280
Seat To remove the seat Remove the bolts, and then pull the seat off.
1
2
EWA10180
WARNING Always adjust both fork legs equally, otherwise poor handling and loss of stability may result.
2 3
This front fork is equipped with rebound damping force adjusting screws and compression damping force adjusting screws.
1. Slot 2. Projection 3. Seat holder
4
ECA10101
2. Place the seat in the original position, and then tighten the bolts. 1. Bolt
To install the seat 1. Fit the slot in the seat onto the projection on the fuel tank, and insert the projection on the seat into the seat holder as shown.
EAU41471
Adjusting the front fork
TIP Make sure that the seat is properly secured before riding.
NOTICE To avoid damaging the mechanism, do not attempt to turn beyond the maximum or minimum settings. Rebound damping force
1. Rebound damping force adjusting screw 4-7
