INSTRUMENT AND CONTROL FUNCTIONS wash with soap and water. If gasoline spills on your clothing, change your clothes.
EAU41360
Fuel tank breather hose
EAU41280
Fuel cock The fuel cock supplies fuel from the tank to the carburetor while filtering it also. The fuel cock has two positions: OFF
4 1. Fuel tank breather hose 2. One-way valve
Before operating the motorcycle: ● Check the fuel tank breather hose connection. ● Check the fuel tank breather hose for cracks or damage, and replace it if damaged. ● Make sure that the end of the fuel tank breather hose is not blocked, and clean it if necessary. TIP If the fuel tank breather hose falls out, reinstall it on the fuel tank cap with the arrow mark on the one-way valve pointed downward as shown. 4-5
1. Arrow mark positioned over “OFF”
With the lever in this position, fuel will not flow. Always return the lever to this position when the engine is not running.
