INSTRUMENT AND CONTROL FUNCTIONS EAU13182
Fuel tank cap
EAU41833
Fuel This motorcycle has been designed to use a premixed fuel of gasoline and 2stroke engine oil. Always mix the gasoline and oil in a clean container before filling the fuel tank. ECA15601
NOTICE Always use fresh gasoline, and fill the fuel tank with a fresh mix just before riding. Do not use premixed fuel that is more than a few hours old.
4 1. Fuel tank cap
To remove the fuel tank cap, turn it counterclockwise, and then pull it off. To install the fuel tank cap, insert it into the tank opening, and then turn it clockwise. EWA11091
WARNING Make sure that the fuel tank cap is properly closed after filling fuel. Leaking fuel is a fire hazard.
Mixing gasoline and 2-stroke engine oil Pour 2-stroke engine oil into a clean container, and then add gasoline. To mix the fuel thoroughly, shake the container from side to side.
1. 2-stroke engine oil 2. Gasoline 3. Container
Recommended fuel: Premium unleaded gasoline only Recommended 2-stroke engine oil: See page 9-1. Fuel tank capacity: 5.0 L (1.32 US gal, 1.10 Imp.gal) Mixing ratios (gasoline to oil): Break-in period: 15:1 After break-in: 30:1 ECA15590
NOTICE Use only unleaded gasoline. The use of leaded gasoline will cause severe damage to internal engine parts, such as the piston rings as well as to the exhaust system. 4-3
