Chassis

Page : 24

Item Qty Part Number Description Notes

1 1 9001195062 SPLITCHASSIS WELDED ASSEMBLY 2 1 9001194057 BRACKET W/ASSY FUEL TANK F/MALE PIVOT 3 1 9410000013 BATTERY DINGO 4 1 9001195068 SPLIT CHASSIS GRILL WELDED ASSEMBLY 5 1 9001195134 BONNETSCOOP GAUZE ALUMINIUM MESH 6 1 9001195079 RECOVERYBOTTLE BRACKET 1 9518000181 RECOVERY BOTTLE 1 9518000182 KIT RADIATOR COOLANT RECOVERY INCLUDES BOTTLE AND BRACKET 7 1 9001194022 BATTERY BRACKET RAISED 8 1 9000495320 BATTERY BRACKET 9 1 9001194131 ALUM SIDE PANELL/H 10 1 9001195021 DASH ASSY 11 1 9001195135 ALUMINIUM DASH FRONT PANEL 12 1 9001195090 OIL COOLER MOUNT W/ASSY 13 1 9001195136 ALUM DASH REAR HALF PANEL 14 1 9001195133 ALUM BONNET-MESH GRILLE NOT INCLUDED 2 9001195085 BONNET CLIP

15 1 9011942076 ARM W/ASSY LIFT INC. BUSHES 9001194207SUPERCEDEDBY 9011942076

16 1 9001194130 ALUM SIDE PANEL R/H 17 1 9001195502 FUEL TANK REAR 1 PIECE BRACKET W/ASSY 18 1 9001195505 FUEL TANK FRONT MOUNT W/ASSY 19 1 9001195015 FRONT OIL RESOVOIR LID W/ASSY 20 2 9001194120 REAR TANK SINGLE OIL PICK UP LID RH W/ASSY 21 1 9001195028 REAR BATTERY SPACER 22 1 9001194145 DASH BRACKET R/H FOR IGNITION & FUEL GAUGE - TNV 23 1 9001194141 BRACKET AUX POWER L/H 24 1 9001194538 FUEL TANK K94/5/P/D/C W/- NUT INSERTS 25 2 9516000030 ELBOW 5/16" BARB TAIL PUSH IN FUEL LINE 26 1 9516000040 CAP FUEL DIESEL YELLOW CLICKER 27 1 9516000075 WEMAFUEL SENDER UNIT 28 2 9516000026 GROMMETFUEL TANK OUTLET 29 1 9001195022 COVER MAIN CONTROL BANK 30 1 9001195023 COVER AUX BANK DUAL REMOTE 31 2 9319387802 HOSETAIL 1” BSPP MALE x 1” WITH DROPPER TUBE 32 1 9001195029 BONNETHANDLE 33 1 9001195051 BASH GUARD BRACKET LH 34 1 9001195053 BASH GUARD BRACKET RH 35 1 9001195052 BASH GUARD
